Dealer Program

Products Available

Resins

201General Purpose:  very thick - use for repair work -  apply to first layer of mold.

215 Spraying:formulated for spray application - repair or part fabrication.

216 Tooling Resin:  formulated for refinishing, surface repair application.  Light sand then buff.

217 Vinyl Ester  production molds along with 216 Tooling resin.

311 Tooling Spray:  production molds along with 216 Tooling resin.

500 2lb Expanding Foam

Gelcoats

Gelcoat Series and their uses:

Gelcoats are ISO/NPG Grade Waterproof.
Can be used below the water line, and also for "Swimming Pool repair & recoating.

300 Brushing:  very thick - use for repair work -  apply to first layer of mold.

306 Spraying:formulated for spray application - repair or part fabrication.

302 Spray& Buff:  formulated for refinishing, surface repair application.  Light sand then buff.

310 Tooling Brush  production molds along with 216 Tooling resin.

311 Tooling Spray:  production molds along with 216 Tooling resin.

317 Super Black   Brightest Black Available        See Spraying Gelcoats

318  Super White  Made from a clear base resin See Spraying Gelcoats

321  Ultra Spray White.  Sprays using  a Preval Sprayer

323 Clear:  used for metal flake or for marble bath ware.

325 Tinted Gelcoats:are pre-tinted from over 300 stock colors.

322 Color Matched Gelcoat:  color matched to your sample provided.

372 Patching Gelcoat.  Gelcoat that applied like body fill.  See Brushing Gelcoats

Specialty Items

554  PVA  Spray on Release agent.  Washes off with water.

550  Honey Wax   Mould release wax.

620  Wax Solution

630  Styrene

636  High Gloss Additive

We offer coloured gel coats to RAL colour numbers.

All our Gelcoats are UNWAXED

Fabric List

Fiberglass Fabrics

163 10 oz plain weave cloth 50 in wide

164 10 oz plain weave cloth 60 in wide

391  1 in Fiberglass sleeve

392  2 in Fiberglass sleeve

166 6 oz plain weave cloth tape  1,2,3,4,6,8 width 10 & 50 yard roll

167 9 oz plain weave cloth tape  2,3,4,6,8 width 10 & 50 yard roll

151  18 oz woven roving.  50 in wide

116  12oz + .75 DBL Bias Knitted 50" Width Stitch Matt

118  (1708)18oz + .75 DBL Bias Knitted 50" Width Stitch Matt

111  18 oz Bi-axial (0°/90°) 50 in wide

Need to check sizes on Stitch matt sizes.

Carbon Fiber Fabric

141 Carbon fiber Tape 1,2,3,4 wide 3 yd, 10 & 50  yd rolls

140  3K, Carbon Fiber Plain Weave 6 oz 50 IN Wide 1, 3 6 10yd & 100yd  roll

141  3k Carbon Fibre Twill 50" wide 6 oz 50 in wide  1,3,6,10yd & 100yd roll

391  392 ,393 , 394 ,395  Carbon fiber sleeve

191 Kevlar 5 oz Tape 10 & 50 yd rolls width 1, 1.5, 2, 3, 4 ,6,

192  5oz Kevlar Felt 63" Roll 3 & 4 in wide length

190 6 oz 58" width Kevlar fabric

391  Kevlar Tubular Sleeve  1 & 2 in

332  Kevlar Repair kit and Skid Plate Kit

Fiberglass Tools & Accessories

Aluminum Rollers   for getting the air out of a laminate

Bristle Rollers   Used for deairing laminates that are curving or uneven.

Mix and Measure Kits

Paper Tubs

Graduated Measuring Tubs  Plastic:

Mixing Sticks wood  6 & 12 in

Latex Gloves

Starter Kits

Paint Brushes  Wood and Plastic Handel

Preval Sprayers

Spray Guns  for Gelcoat

Balsa Wood   core material

Products   &  Application

Resin Types:

Polyester General Purpose

RAYPLEX® #201 Fiberglass Resin is the same high-strength polyester resin that is used to build most boats. Can be used alone or with fiberglass tape, cloth or mat to repair damaged fiberglass boats, snowmobiles, jet skis, bathtubs,  showers, sinks and hot tubs.

Isophthalic

RAYPLEX® #215 Fiberglass Isophathalic Resin is 100% waterproof and designed specifically to be used        below the water line in marine applications. It can also be used for interior and exterior home repairs including            tubs, showers, sinks, pools, hot tubs, and more. If additional structural strength is needed for more severe    repairs like larger holes, cracks or damaged surfaces, the use of additional layers of RAYPLEX®Fiberglass Cloth or Mat is recommended. The product cures in 2 hours, resulting in a non-shrinking and durable repair. Can be used on multiple  surfaces including concrete, wood, fiberglass, metal and more, and works as a waterproof sealer.

Vinyl Ester

 RAYPLEX® #217 Vinyl Ester Resin ( promoted )offers increased strength, corrosion resistance   and durability and are used in a wide variety of applications. While vinyl ester resins are classified as polyester-based             formulations, they are actually an intermediate between a polyester backbone and epoxy terminations on the ends of the molecules. They are based on either bis phenol-A or novolac chemistry with methacrylic acid forming the         polymer.

It is compatible with all gel coats and requires RAYPLEX® Liquid Hardener (MEKP).

**Once ordered...due to a shorter shelf life this requires a few extra days to prepare

                                                                                 Gelcoats

Rayplex Gelcoats are ISO/NPG Grade and are Waterproof. Which means they can be used below the waterline.


* Gelcoat types Available and Uses:

            Brushing- Used to repair chips, deep scratches, dock dings, pinholes and gouges in fiberglass

            Spraying- Formulated for application using gelcoat spray guns

            Spray & Buff- Formulated for refinishing, surface repair application. Light sand then buff.

            Patching Gelcoat-Gelcoat that applied like body fill.

            Tinted Gelcoat- Can be ordered in Brush or Spray formulation, are pre-tinted from over 300 stock colours.
            **Use RAL chart to Colour

* Gelcoat Repair Kits *

 Our Gelcoat repair kits are available in various colours and kit sizes of 250 ML, 1 Lt, 3.78Lt, plus they include everything you need to tackle any minor gelcoat repair. Not sure on colour...then try our regular Colour Match Kits located on our previous page. Deluxe kits include sandpaper and course and fine buffing compound.

  White Blue  Black  Clear Red

Gelcoat Polishing Kit

Available in 30 and 120 ML sizes. Includes sandpaper, course and fine buffing compound & high Gloss Additives

**This additive is designed to significantly improve the working properties, appearance and longevity of traditional gelcoat spray patches.

Pigments

Our colour pigments are pastes for tinting polyester, vinyl ester, and epoxy resins. Available in 30 125 250 and 1 Lt sizes.

Fiberglass Repair Kits  Small and Large

Contains the resin and fabric plus rollers, brushes, mixing containers, Gloves.

 See web site for complete contents of kit.

Kevlar Repair Kits- Complete kits for repairing kevlar canoes.

Skid Plate Kit- for canoe fronts.

Fabrics

Matting- Fiberglass Matting is the most common everyday kind of reinforcement

Woven Roving- Woven Roving is made from continuous glass fiber roving which are interlaced into heavy weight fabrics.

Cloth & Cloth Tape- All of our fiberglass cloths are compatible for use with our polyester resins, epoxy resins or vinyl ester resin.

Specialty Fabrics- 1708, Double Bias, Stitich Matt, Kevlar, Carbon fibre

TOOLS

            Spray Guns

            FRP Rollers in Aluminum and plastic

Chemicals & Solvents

            Airdry or Wax Solution- Add 5% Wax Solution/Air Dry to the unwaxed polyester resin, vinyl ester resin, or gel coat to make it non-tacky when dry. It contains paraffin wax suspended in styrene solvent. The wax rises to the surface as the material cures and seals the surface from oxygen.

            Acetone- Acetone is popular solvent  used to remove fiberglass or epoxy resin from tools, spray guns and equipment also removes wax from gelcoat surfaces.

            Styrene- Styrene is the recommended and accepted thinner for polyester resins and gelcoats. Most gelcoats can be thinned 2-5% to make them suitable for ordinary spray equipment or other special purposes.

            PVA- Polyvinyl alcohol (PVA) is often utilized as a mold release agent in industries such as plastics, rubber, and composites. PVA should be used to aid in the release of parts from a mold

         Waxes- Compounded with the purest grade carnauba wax, plus special binders and             spreading agents, Honey Wax has been the leading choice in mould release             agents for decades.

Putty

            Fiberours Putty- Fiberous putty is used to bond or repair for maximum strength.

            Fairing Putty- Fairing Putty is a lightweight two-component polyester putty that can be used for fairing, filling, shaping, and repair.

            Expanding Foam- Expanding Urethane Foam is a two-component, urethane foam system available in 4 separate density formulations by weight per cubic foot.

Fillers

         Cabosil- A white, free-flowing powder, Cabosil is a thickening agent primarily added to thicken resin.

         Milled Fibers- Primary use is as a reinforcement in composites to increase mechanical properties.

            (impact,tensile, compressive and flexural), improve dimensional stability and minimize evated temperatures.

         Copped Strand- Used to increase tensile and compressive properties of any resin, even concrete.

         Talc- Talc is the major component of any body filler. It is a sandable filler added for fairing and smoothing the finish of fiberglass lamination.

         Glass Bubbles- Lightweight hollow glass spheres used as an extender and thickener for resins. Fine detail reproduction when used in casting. Strong, will hold fasteners when used to fill holes.

More information about any of these products is available at our Website   www.rayplex.ca

If you perfer  give us a call.  905 579 1433
